26
ENGINE
Briggs & Stratton
Make Briggs & Stratton®,
Intek Series
TM
7180 OHV
Displacement 40.03 cu in. (656 cc)
Electrical System 12 Volt, 16 amp Alternator, Battery: 230 CCA
Oil Capacity 62-64 oz (1,8-1,9 L)
Spark Plug Gap 0.030 in. (0,76 mm)
Spark Plug Torque 180 in-lbs (20 Nm)
Briggs & Stratton
Make Briggs & Stratton®,
Intek Series
TM
8240 OHV
Displacement 44.18 cu in. (724 cc)
Electrical System 12 Volt, 16 amp Alternator, Battery: 230 CCA
Oil Capacity 62-64 oz (1,8-1,9 L)
Spark Plug Gap 0.030 in. (0,76 mm)
Spark Plug Torque 180 in-lbs (20 Nm)
Service Parts Part Number
Resistor Spark Plug 491055
Life Long Platinum 5066
Spark Plug
Air Filter 499486
Pre-Cleaner 273638
Oil Filter 492932
Fuel Filter 691035
CHASSIS
Fuel Tank Capacity Capacity: 2.6 gal (10 L)
Rear Wheels Tire Size: 22 x 8.8
Inflation Pressure: 10 psi (0,68 bar)
Front Wheels Tire Size: 15 x 6.6
Inflation Pressure: 14 psi (0,96 bar)
TRANSMISSION
K46
Type Hydrostatic Tuff Torq K46
Engine Oil Synthetic 5W30
Speeds Forward: 0-5.4 MPH (0-8,7 km/h)
@ 3400 rpm Reverse: 0-2.3 MPH (0-3,7 km/h)
Continuous Torque 170 ft-lbs
Output
Drawbar Rating 227 lbs (103 kg)
Maximum Weight 675 lbs (306 kg)
on Axle
MOWER
Width of Cut 40” (102 cm)
Number of Blades 2
Base Deck Platform Rear Discharge
Cutting Height 0.98-3.15 in. (2,5-8.0 cm)
Cutting Positions 7
DIMENSIONS
Overall Length 79.9” (2030 mm)
Overall Width 42.1” (1070 mm)
Height 46.9” (1190 mm)
Weight 595 lbs (270 kg)
SPECIFICATIONS
PARTS AND ACCESSORIES
Contact an authorized dealer for details.
www.simplicitymfg.com
