Simplicity S20 User Manual

76
HOW TO USE POWER NOZZLE
OPERATION
1. Turning on the Power Nozzle
The power nozzle can only be turned on if the
canister is also turned on (canister on / off
switch is located on the main body). The
power nozzle on / off switch is located on the
handle. Simply press the switch forward to
engage the power nozzle.
2. Using the Power Nozzle
To achieve best cleaning results, slowly pass
the power nozzle back and forth over the
carpet or floor.
3. Remove / Insert the Wand From The Power
Nozzle
Removing the wand from the power nozzle
allows you to use the cleaning tools for
baseboard or ceiling cleaning. To do this first
turn the power nozzle and canister off. Then,
press the nozzle release button and pull the
wand out. To reinsert the wand into the power
nozzle, simply press the back into the neck of
the power nozzle. The wand will then “click”
back into place.
DIAGRAM 1 REAR VIEW OF POWER WAND AND NOZZLE ASSEMBLY
DIAGRAM 2 FRONT VIEW OF POWER WAND AND NOZZLE ASSEMBLY
Wand Extension Grip (to extend wand)
Handle
Telescopic Wand
Power Nozzle
Handle
Telescopic Wand
Power Nozzle
On/Off Control
Wand Release Button
Wand Extension Grip
(to extend wand)
Nozzle Release Button
S20-Simplicity-1214 2004.12.14 11:55 AM 7
