Simplicity Stallion Series - Specifications; Engine, Transmission, Chassis Specs

29
Specifications
ENGINE:
25 HP* Kohler
Make Kohler
Model Command CV730S
Horsepower 25 @ 3600 rpm
Displacement 44.2 Cu. in (725 cc)
Electrical System 12 Volt, 15 amp. Alternator, Battery: 340 CCA
Oil Capacity 4.2 pt. ( 2.0 L) w/ Filter
27 HP* Kohler
Make Kohler
Model Command CV740S
Horsepower 27 @ 3600 rpm
Displacement 44.2 Cu. in (725 cc)
Electrical System 12 Volt, 15 amp. Alternator, Battery: 340 CCA
Oil Capacity 4.2 pt. (2.0 L) w/ Filter
CHASSIS:
Fuel Tanks Capacity: 9 Gallons (34 L) Total
Rear Wheels Tire Size: 23 x 10.50 -12
Inflation Pressure: 15 psi (1,03 bar)
Front Wheels Tire Size: 13 x 5.00-6
Inflation Pressure: 25 psi (1,76 bar)
TRANSMISSIONS:
HydroGear BDP-10A / Parker TF-024
Type Pump and Wheel Motor
Hydraulic Fluid Mobil 1™ 15W-50 synthetic oil or
Castrol Syntec™ 5W-50 oil,
Speeds Forward: 0-8.5 MPH (0-13.68 km/h)
@ 3400 rpm Reverse: 0-5 MPH (0-8.05 km/h)
Continuous Torque 315 ft. lbs. (427 N.m.)
Output
Maximum Weight 3000 lbs. (1360 Kg)
on Axle
DIMENSIONS:
Overall Length 81” (206 cm)
Overall Width 72” (183 cm)
Height 54” (137 cm)
Weight (apx..) 1245 lbs. (564 Kg)
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors.
