FastCut Hydro Drive ZTR
7/2005 3
TP 300-7237-IR-HZ-N
Quick Setup List -
Page Setup Procedure Steps to Perform
4 Uncrating ❏ Remove crate & banding.
❏ Place transmissions in PUSH position & roll off skid.
4 Battery Activation & ❏ Charge the battery
(Note: proceed with other setup steps
Installation
while battery is charging).
❏ Test battery with hydrometer or load-tester.
❏ Install & secure battery.
5 Rider Assembly ❏ Install the seat and connect the seat switch
❏ Install ground speed control levers.
6 Check Fluid Levels ❏ Fill & check Engine oil level.
❏ Check transmission fluid level.
❏ Reduce & check tire pressures
(Front tires 40 psi, rear tires 15 psi).
7 Mower Assembly ❏ Torque mower blade bolts.
7 Lubrication ❏ Lubricate all grease & oil points.
8 SAFETY CHECKS ❏ Check for LOOSE HARDWARE.
❏ Check all OPERA
T
OR CONTROLS.
❏ Test P
ARKING BRAKE.
❏ Perform MO
WER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
❏ Perform SAFETY INTERLOCK SYSTEM CHECK.
8 Burnish Electric Clutch ❏ Burnish electric clutch
(run for 15 seconds, repeat 10 times)
.
❏ Repeat MO
WER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
