1

SimpliFire • SF-ALL40-BK, SF-ALL48-BK, SF-ALL60-BK, SF-ALL84-BK • 2040-981 Rev. M • 7/21

Model(s):

WARNING: To reduce risk of re, electrical shock, or personal injury, read all instructions

before using appliance.

Owner’s Manual

Installation and Operation

DO NOT DISCARD THIS MANUAL

NOTICE

• Leave this manual with

party responsible for use

and operation.

DO NOT

DISCARD

• Important operating

and maintenance

instructions included.

• Read, understand and follow

these instructions for safe

installation and operation.

SF-ALL40-BK

SF-ALL48-BK

SF-ALL60-BK

SF-ALL84-BK

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN

THIS PRODUCT.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE

TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR

PROPERTY DAMAGE.

Congratulations!

Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning replaces.

The SimpliFire electric replace you have selected is designed to provide the utmost in safety, reliability, and e󰀩ciency.

Printed in China - Copyright 2021

Allusion Series:

SimpliFire, a brand of Hearth & Home Technologies

7571 215

th

Street West, Lakeville, MN 55044

www.hearthnhome.com

Questions and Answers:

L
Leah SheltonAug 19, 2025
Why doesn't my SimpliFire Indoor Fireplace remote control work?
- P
  pottskristenAug 19, 2025
  If your SimpliFire Indoor Fireplace remote control isn't working, there are several potential causes. First, the batteries might be low or dead, so try replacing them. Ensure that nothing is blocking the remote receiver and that you are pointing the remote directly at it, and also move closer to the appliance. If your appliance has a power switch, make sure it is in the "I" (on) position. Finally, a control board malfunction might be the reason, and in that case, the control board (PCB) should be replaced.
J
josephgainesAug 21, 2025
Why does my SimpliFire Indoor Fireplace keep tripping the circuit breaker?
- D
  david86Aug 21, 2025
  Your SimpliFire Indoor Fireplace might be tripping the circuit breaker because it's exceeding the current rating of the breaker or fuse, possibly due to other appliances operating on the same circuit. To resolve this, install the unit onto a dedicated 15 amp circuit.
K
Kevin LopezAug 23, 2025
What to do if SimpliFire Indoor Fireplace won't turn on using manual controls?
- M
  Melissa WoodAug 23, 2025
  If your SimpliFire Indoor Fireplace won't turn on using the manual controls, first ensure that the appliance is plugged into a working electrical outlet. If it is hard-wired, review the wiring instructions to ensure correct connection. Check your fuse/breaker panel to ensure there is incoming power from the electrical outlet or electrical box. If none of these steps work, the control board (PCB) may be defective and require replacement.
R
Rita EllisAug 26, 2025
Why won't the heater on my SimpliFire Indoor Fireplace turn on?
- S
  sweeneydavidAug 26, 2025
  There are several reasons why the heater on your SimpliFire Indoor Fireplace might not be working, even if the flame is on. If the remote is in thermostat mode, the room temperature (measured at the appliance thermistor) might be higher than the set point on the remote. Try increasing the thermostat set point or exiting thermostat mode. The appliance may have overheated, causing the safety thermal switch to trip. Unplug or turn off power at the circuit breaker and allow it to cool for 15 minutes, then restore power. A defective main control board or heater assembly could also be the cause, requiring replacement of either the control board (PCB) or the heater assembly.
E
ericarodriguezAug 27, 2025
Why do the lights dim when my SimpliFire Allusion is on?
- R
  Rebecca DavisAug 28, 2025
  If the lights in the room dim when your SimpliFire Indoor Fireplace is on, it indicates that the unit is drawing close to the circuit's current rating. To fix this, install the unit onto a dedicated 15 amp circuit.
W
Willie HernandezAug 30, 2025
Why does my SimpliFire Allusion heater shut off automatically?
- D
  Daniel BurtonAug 30, 2025
  Your SimpliFire Indoor Fireplace heater might shut off automatically because the room temperature (temperature at the appliance thermistor) is higher than the set point on the remote. To solve this, increase the thermostat set point on the remote or exit thermostat mode. Alternatively, the appliance may have overheated, causing the safety thermal switch to trip. Unplug or turn off the power at the circuit breaker and allow the unit to cool for 15 minutes before restoring power.
S
Steve MillerSep 1, 2025
Why is my SimpliFire Allusion Indoor Fireplace making so much noise when the heater is on?
- J
  Judith CainSep 2, 2025
  Excessive noise when the heater is on in your SimpliFire Indoor Fireplace could be due to interference with the fan blade. Inspect the heater assembly and fan for any obstructions or interference. It could also be a sign of a defective blower motor, which would require replacing the heater assembly.
S
Scott EvansSep 3, 2025
How to fix a SimpliFire Allusion flame that won't move?
- C
  Chad PatelSep 4, 2025
  If the flame in your SimpliFire Indoor Fireplace isn't moving, the flame rotisserie motor might be stalled or malfunctioning. Try cycling the unit on and off. If the problem continues, inspect the rotisserie and motor for any blockage or interference. If you find no interference, the control board (PCB) and rotisserie motor may need to be replaced.
K
katie00Sep 6, 2025
Why is the flame shuddering in my SimpliFire Allusion Indoor Fireplace?
- S
  Shaun EdwardsSep 6, 2025
  A shuddering flame in your SimpliFire Indoor Fireplace can occur if the flame rotisserie is contacting other internal components when spinning. Make sure the rod is straight, properly mounted, and spinning freely without hitting other components. It can also be caused by a defective flame rotisserie motor, which would need to be replaced.
C
Chelsea IbarraSep 8, 2025
Why does my SimpliFire Indoor Fireplace turn on by itself?
- J
  Justin HamiltonSep 8, 2025
  If your SimpliFire Indoor Fireplace turns on by itself, it could be due to a defective control board (PCB), which would require replacement. For units manufactured before 2019, a similar infrared signal from another remote might be causing this issue. Replacing the control board (PCB) is also the solution in this case.

SimpliFire Allusion Series Specifications

General

Brand	SimpliFire
Model	Allusion Series
Category	Indoor Fireplace
Language	English

Summary

Important Instructions

Safety Precautions for Operation

Safety instructions to reduce risk of fire, electric shock, and injury.

Warranty Information

Limited Lifetime Warranty Details

Details warranty coverage, terms, and exclusions for the fireplace.

Getting Started

Location Selection Guidelines

Clearance to Combustibles

Specifies minimum clearances required from combustible materials.

Electrical Supply Requirements

Outlines the electrical requirements for installation and operation.

Installation Procedures

Recessed Installation in 2x6 Wall

Instructions for recessing the appliance in a 2x6 framed wall.

Recessed Installation in 2x4 Wall

Instructions for recessing the appliance in a 2x4 framed wall.

Securing the Appliance

Direct Wall Mounting with Bracket

Details mounting the bracket and appliance directly on walls.

Masonry Wall Mounting

Hanging Appliance on Bracket

Electrical Connection and Wiring

Instructions for hard-wiring or using a power cord.

Power Cord Installation

Operating Instructions

Manual Control Panel Operation

Remote Control Operation

Thermostat and Temperature Control

Resetting Temperature Cutoff Switch

Maintenance

General Maintenance and Safety

Cleaning Glass and Metal Surfaces

Troubleshooting

Troubleshooting Common Issues

Common issues, possible causes, and corrective actions.
