Pre-Assembly Information
Part Description
Hardware Description
ALLEN KEY BOLT
M6 x 35 mm
QTY 30
ALLEN KEY BOLT
M6 x 15 mm
QTY 16
WASHER
Ø 20 / Ø 8 x 1.5 mm
QTY 46
ALLEN KEY
4 mm
QTY 1
1
5 6
2 3 4
J K L
M
LEG
QTY 2
SHELF PIN
QTY 4
Model # AXCJAG-09-N
LEG
QTY 2
BACK PANEL
QTY 2
CONNECTOR
QTY 1
QTY - 4
M4 x 20 mm - QTY - 4
M4 x 30 mm - QTY - 4
FURNITURE TIP OVER RESTRAINT
QTY - 2 SETS
