9
Flood diagnostic is explained on page 27. You should refer to this if you
have water pouring onto the floorThe display will show “ ” and you will
hear rapid short beep continuously to remind you about this problem.
IMPORTANT: Components in the washing machine are designed to be used
with water no hotter than 70°C. If your water supply is too hot, you should
have a temperature limiting valve fitted by a qualified plumber.
Hot
Temp.
Proportion of Hot and Cold water based on temperature selection.
Descriptions
Water from
HOT valve
Water from
COLD valve
Warm
Very hot
Cold
for normally soiled, colourfast garments (e.g.
shirts, night dresses, pyjamas....) in linen,
cotton or synthetic fibres and for lightly
soiled white cotton (e.g.underwear).
for delicate items (e.g. net curtains), mixed
laundry including synthetic fibres and
woollens bearing the label pure new wool,
machine washable, non-shrink.
for normally soiled white cottons and linen
(e.g. teacloths, towels, tablecloths, sheets...).
100 % 0 %
65 % 35 %
50 % 50 %
10 % 90 %
3.3
WATER LEVEL BUTTON
Choose the water level by pressing
Water Level button.
You can select:
Use only the amount of water you
need for the wash load.
1.
2.
Full, High , Medium and Low
CHOOSE THE WATER LEVEL
Choose the water level by pressing Water Level button. Use only the amount of
water you need for the wash load.
1) Model SWT6055TMWA Maximum mass of dry cloth is 6.0 kg.
2) Model SWT6555TMWA Maximum mass of dry cloth is 6.5 kg.
3) Model SWT7055LMWA Maximum mass of dry cloth is 7.0 kg.
4) Model SWT7055TMWA Maximum mass of dry cloth is 7.0 kg.
Water
Level
Appropriate Clothes Load (kg)
4 to 6.0 5 to 7
Full
Medium
High
Low
0 to 1.5 0 to 1.5
1.5 to 3 1.5 to 3
3 to 4.5 3 to 5
Model
SWT6555TMWA
SWT7055LMWA
SWT7055TMWA
Model
SWT6055TMWA
