Simrad AP70 MK2 Quick Start Guide

|
3
AP70 MK2 Quick Start Guide
The screen
Status icons
Heading repeater
Mode info panel
Mode indication
Work prole
Rudder command
Rudder bar
Icon Description
Icon available if a thruster is installed. The icon will be shaded when the
truster is deactivated for steering
Active alerts. Red icon for alarms, yellow for warnings
Locked control unit
Picture freeze indicator. Two dots alternate slowly to show that the screen
is alive and that information from sensors is updated
Command transfer and unit lock
CMD
CMD
Take command
Command transfer - Lock other units
Activating and deactivating the thruster
CMD
3s
