Simrad TP10 - User Manual

Other manuals for Simrad TP10

Service Manual44 pages

Questions and Answers

A
ashleyrobertJul 27, 2025
What to do if Simrad TP10 loses course and goes into Standby mode?
- Q
  qhollowayJul 27, 2025
  If your Simrad Marine Equipment suddenly loses course and goes into Standby mode, it could be due to a few reasons. The power might have been interrupted briefly, or the voltage is low, so uprate batteries. It could also be that the cable used to the socket is too small, or that there is an intermittent connection. Check all connections and charge batteries. To resolve this, increase the size of the cable.
C
cparkAug 3, 2025
Why is Simrad TP10 helm hard over with continuous alarm?
- M
  melissa93Aug 3, 2025
  If the helm is hard over and the alarm is continuously on for your Simrad Marine Equipment, it means that the steerage way is insufficient to control the course, or the sails are aback. To solve this, reset the vessel on course and re-engage pilot.
W
warren67Aug 10, 2025
What to do if Simrad Marine Equipment cannot select Steer To Wind mode?
- C
  ccantrellAug 11, 2025
  If you cannot select Steer To Wind mode on your Simrad Marine Equipment, it could be due to a few reasons. The masthead unit might not be connected, or the SimNet system is not switched on or powered. To resolve this, check connections and check that the system is on.
J
Jacqueline LeonAug 18, 2025
What to do if Simrad TP10 Marine Equipment loses course under Steer To Wind mode?
- T
  Timothy RomeroAug 18, 2025
  If your Simrad Marine Equipment loses course under Steer To Wind mode, the apparent wind has become too light to give a consistent direction. To solve this, change to Compass mode.

Summary

Operation

Autopilot Mode

Adjusting Course

Auto Tacking and Gybing

Advanced Features

Nav Mode

Steering to a waypoint using GPS/chartplotter data via SimNet or NMEA 0183.

Steer To Wind

Sailing to a specific apparent wind angle using wind data via NMEA or SimNet.

Configuration

Calibration Mode

Accessing calibration settings to adjust Response Control and Seastate for optimal performance.

Adjusting Response Control (1-9)

Setting the tiller's movement proportionality to heading error for responsive steering.

Adjusting Seastate (On;Off)

Enabling a deadband to reduce corrections in rough seas and manage battery usage.

Installation

Fitting the Tillerpilot

Guidelines for physically mounting the Tillerpilot unit onto the boat's tiller.

Electrical Installation

Instructions for wiring the Tillerpilot for power, SimNet, and NMEA data connections.

Interfacing via SimNet

Connecting the Tillerpilot to other SimNet-compatible equipment for data sharing on the network.

Configuring the TP on the SimNet Bus

Setting Tillerpilot operation modes (System/StandAlone) for data sharing on the SimNet bus.

Interfacing via NMEA

Auto Compass Calibration

Simrad TP10 Specifications

General

Power Supply	12 V DC
Auto Seastate	Yes
Course Accuracy	±1°
Maximum Boat Length	10 m
Maximum Thrust	68kg (150lbs)
Power Consumption	0.5 A
Operating Temperature	-10 to 55 °C
Storage Temperature	-20 to 70 °C
