CR40/42/50 MKII Installation manual Chapter 9
122
Flush mounting for CR40/42:
Removable corner.
Min. clearance for
cables: 15 cm.
See template for instructions!
337 (13.3)
347 (13.7)
353 (13.9)
365 (14.4)
192 (7.6)
202 (7.9)
208 (8.2)
220 (8.7)
