DRAFT

Frequency Setting. Operate Space Bar, following screen appears:

A1 Frequency

Enter Required Frequency in MHz

[Enter] accept [ESC] exit

Enter frequency then press Enter to accept. Select next channel.

Save NVM data to Radio

Verifying NVM data in radio *

Verify successful, radio is programmed *

NVM data

00: 0010 10: 0003 20: 0000 30: 0000

01: 0000 11: 3011 21: 0000 31: 0000

02: 2020 12: 1111 22: 0000 32: 0000

03: 8008 13: 1111 23: 0000 33: 0000

04: 1010 14: 1333 24: 0000 34: 0000

05: 3111 15: 3333 25: 0000 35: 0000

06: 1101 16: 3333 26: 0000 36: 0000

07: 0000 17: 3300 27: 0000 37: 0000

08: 0004 18: 3333 28: 0000 38: 0000

09: 0411 19: 3333 29: 0000 39: 0000

0A: 1111 1A: 3333 2A: 0000 3A: 0000

0B: 1111 1B: 33FF 2B: 0000 3B: 0000

0C: 1333 1C: 3098 2C: A1A2 3C: 0000

0D: 1111 1D: 309A 2D: FFFF 3D: 0010

0E: 1110 1E: 0000 2E: 0000 3E: 1010

0F: 0030 1F: 0000 2F: 0000 3F: 016A

Any key to continue, [ESC] to exit

• Final legend.

• Following legends will be displayed briefly in turn:

Reading existing data from radio

Writing NVM data to radio

Clone Radio

Connect SOURCE radio, press any key when ready

Any key to continue, [ESC] to exit
