NSS evo3S | Quick Guide - EN
System Controls dialog
Used for quick access to system settings.
Activate the dialog by:
• Pressing the System Controls button.
• Swiping from the top of the screen.
• Pressing the Power key.
¼ Note: The content of the System Controls dialog depends on connected equipment
and active panel.
Application pages
D
A
E
B
C
A Home/pages button
B Application panel
C Menu button
D Instrument bar
E Control bar
Adjust panel size
You can adjust the panel sizes in a split page.
1. Tap the adjust split button in the System Controls dialog to show the resize icon
2. Drag the resize icon to set preferred panel size
3. Save the changes by tapping the screen.
Charts
• Zoom the chart by using spread or pinch
gestures or by using the zoom buttons.
N
