Specications
GENERAL
Power supply: 12 V DC battery system
Nominal operating voltage: + 13.6 V DC
Low battery alert: 10.5 V DC +/- 0.5 V
Over voltage protection: > 15.8 V +/- 0.5 V
Current drain (Transmit): ≤ 6 A @ 25 W / 1.5 A @ 1W (12 V DC)
Current drain (Receive): Less than 450 mA in standby
Replacement Fuse: 8 A, Glass type 3 AG; 32 mm (1.25”)
Temperature range: -20 ºC to +55 ºC (-4 ºF to 131 ºF)
Usable channels: International, USA, Canada, Weather
(country specific)
Mode: 16K0G3E (FM) / 16K0G2B (DSC)
DSC mode: Class D (Global) with dual receiver
(individual CH70)
Standards - EU: EN60950-1, IEC 60529, EN 60945, EN
301 843-1 V2.1.1, EN301 843-2 V2.1.1,
EN 301 025 V2.1.1, EN 300 698 V2.1.1
Standards - US/CAN: FCC Part 80, RSS-Gen Issue 4, RSS-182
Issue 5
Standards - INT: AS/NZS 4415.1:2003
Frequency range (Transmitter): 156.025 - 157.425 MHz
Frequency range (Receiver): 156.050 - 163.275 MHz
Channel spacing: 25 KHz
Frequency stability: ± 5 ppm
Frequency control: PLL
PHYSICAL
LCD display (viewing): 42 mm x 34 mm (1.65” x 1.3”), FSTN
Contrast control: Yes
Backlight control: Yes
VHF antenna connector: SO-239 (50 ohm)
GPS antenna connector: SMA (female)
Waterproof: IPx7
Dimensions: W=166.7 mm (6.56”) x H=89.2 mm
(3.5”) x D=161.4 mm (6.35”) - without
bracket
