GD10P User Manual Page 22 of 44 850-811250-Rev.06b
The menu map on the previous page, shows the complete list of available commands in the
HART® interface of GD10. Most of the commands are only requests to read information from
the detector. The commands shaded as grey with bold text gives the operator possibility to make
changes to individual parameters, and these commands are described further in the following
sections.
5.2.4 Detailed description of selected commands
When one of the following commands are activated, the operator is navigated to one or several
data input screens where detailed data can be entered, or predefined options selected. Detailed
navigation between the commands is not explained, as this is part of the user interface of the
actual HART® communicator.
5.2.4.1 TAG (Basic setup)
The operator can write an alphanumeric text, max 8 characters. Default is “GD10”.
5.2.4.2 Long tag (Basic setup)
The operator can write an alphanumeric text, max 32 characters. Default is empty.
5.2.4.3 Descriptor (Basic setup)
The operator can write an alphanumeric text, max 16 characters. Default is “SIMTRONICS A/S”.
5.2.4.4 Date (Basic setup)
The operator can write a date on the format MM/DD/YY. Default is “**/**/**”.
5.2.4.5 Message (Basic setup)
The operator can write an alphanumeric text, max 32 characters. Default is “SIMTRONICS A/S”.
5.2.4.6 Final asmbly num (Basic setup)
The operator can write an alphanumeric text, max 8 characters. Default is “0”.
5.2.4.7 SET RESPONSE TIME (Detailed setup)
The operator can choose between two response modes. Default is “5s”.
