Simu SIMUBOX 220/12 TRI - Page 8

UVW
Fdc
S1
Fdc
S1
Fdc
S2
Fdc
S2
Secu
Mot
Secu
Mot
1 2
EN
2/6
S1
S2
Manual override
Short crank (included)
Override by chain
• 10 meter chain
S1
S2
Override with long crank
• Ring
• Crank handle with hook
For mounting
Installation with block rod
Installation with bracket +
mounting bracket
1.2 - Front face description
End limit adjustment screws
Inputs for
command
connection and
power supply
Extra switches
MOTOR RANGE
2
ACCESSORIES
3
Terminal plug
power supply connection
command connection
Traction stops
Reference Description
Torque
(Nm)
Speed
(rpm)
Shaft
diameter
(mm)
Power supply
Power
consumption
(W)
Intensity
at nominal
torque
(A)
Operating time
(min)
Nb
cycles /
hour
Cos ϕ IP
Weight
(Kg)
Limit
switch
capacity
(turns)
Operating
temperature
2009132
SIMUBOX
220/12 TRI
220 12
30
400V 3~ -
50Hz
850 1.6
10 15 0.9 44
17
25 -10°C - + 40°C
2009152
SIMUBOX
300/12 TRI
300 12 1050 1.9 17
2009133
SIMUBOX
430/08 TRI
430 08 1100 2.1 18
