Sinclair AMC-15A Service Manual

No Description Part Code
Note
Price Code
1 PACKING BOTTOM PSF 410284-0Y-1 AH
2 WHEEL TWP 290025-00XY-H AC
3 BASE 210523-BY-1 AU
4 RUBBER STOPPER 310025-0Y-1 AB
5 COMP, 44A293AJ-FEKC 700167-00-1 BM
6 PARTITION 210524-FY-1 AL
7 FRONT PANEL 210574-0Y-1-H-2 AK
8 UPPER COVER-FRONT (COLD AIR)
210575-0Y-1-H
AG
9 OUTLET FOR COLD AIR
210578-0Y-4-H
AF
10 STRAINER 740007-30XY AL
11 CAPILLARY 1.0x2.2xL500 780203-0Y-14 AR
12 CAPILLARY, 1.0x2.2xL550 780203-0Y-37 AR
13 DISCHARGE TUBE
780222-BY-4
AG
14 CONDENSER 710156-CY-3 BL
15 SUCTION TUBE 780223-0Y-7 AK
16 EVAPORATOR 710157-0Y-4 BK
17 Horizontal blade 210534-0Y-3-H AC
18 Join for horizontal blade 210580-0Y-3-H AC
19 LEFT SIDE PLATE 210527-AY-1-H AH
20 COND FILTER 210533-AY-12-H AH
21 EVA FILTER 210532-AY-12-H AH
22 HOUSING BLOWER,LEFT BOTTOM 410330-0Y-1 AP
23 WHEEL BLOWER φ215x95 ABS+GF 210631-0Y-2 AN
24 HOUSING BLOWER,RIGHT BOTTOM 410331-0Y-1 AP
25 HOUSING BLOWER,LEFT TOP 410254-0Y-1-X AP
26 WHEEL BLOWER φ215x95 ABS 210631-0Y-1 AM
27 HOUSING BLOWER,RIGHT TOP 410253-AY-1-X AP
28 CAP, 3.0uFx450VAC 730049-00XY AE
29 CAP, 3.5uF 450V 730052-0Y-1 AE
30 MOTOR BRACKET 110276-0Y-1 AH
31 OUTER MOTOR 720071-0Y-3-AL BA
32 INNER MOTOR 720078-0Y-3-AL AZ
33 DISPLAY PCB 800145-BY-1-Q AS
34 CONTROL PANEL 210577-0Y-1-H AL
35 PACKING TOP PSF 410283-0Y-1 AH
36 MAIN PCB 800161-0Y-4-5-Q AX
37 Clip for capacitor 190004-0B4Y AB
38 CAPACITOR,30uF 450VAC 730002-20XY AP
39 OUTLET FOR HOT AIR,RIGHT 210537-AY-1 AF
40 OUTLET FOR HOT AIR,LEFT 210536-BY-1 AF
41 UPPER COVER-BACK (HOT AIR) 210576-0Y-1-H AG
42 PIPE OUTER ,Φ150mm 210581-0Y-2 AD
43 PIPE EXHAUST, φ150mm 290008-A0XY AN
44 OUTLET FOR HOT AIR 210579-0Y-4-H AG
45 WHEEL WATER 210186-0BAY AL
46 COVER FOR WATER MOTOR 210538-AY-1 AD
47 WATER MOTOR , 230V/50Hz 720075-BY-3 AX
48 SWITCH, KW3A-16ZA2-C075 16A 750035-0Y-1 AL
49 FLOATER 220001104Y AC
50 wire holder-bottom 210467-AY-3 AC
51 MAIN BRACKET 110196-AY-1 AD
52 RIGHT SIDE PLATE 210526-AY-1-H AH
53 Back PANEL 210574-0Y-1-H-2 AH
54 REMOTE CONTROLLER 800032-0Y-32-K AT
55 Control panel receiver 400MM 800180-0Y-1-A AK
56 Cover top 310029-0Y-1 AB
POWER CORD 760043-0Y-3-1 AF
CARTON
610077-0Y-11 AL
PVC transparent tube xΦ19xL600 230007-80XY AB
MODEL: AMC-15A
