DC Inverter Duct Type Air Conditioner Installation and Operation Manual
36
Warning:The height of installation for the indoor unit should be 2.5m above.
8.1.2 Prole dimensions of outdoor unit
Fig. 36
Table 7 Unit: mm
Item
Model
A B C D E
ASGE-18AIA WK
955 396 700 560 360
ASGE-24AIA WK
980
427 790 610 395
ASGE-36AIA WK
ASGE-36AIA-3 WK
1107 440 1100 631 400
ASGE-42AIA-3 WK
1107 440 1100 631 400
8.1.3 Schematic diagram of installation spaces
Fig. 37
8.5.3 Precautions on Installation of Outdoor Unit
To ensure the unit in proper function, selection of installation location must be in accordance with following
principles:
1. Outdoor unit shall be installed so that the air discharged by outdoor unit will not return and that sufcient
space for repair shall be provided around the machine.
