Sinclair ASH-09AIE2 Service Manual

55
Installation and Maintenance
Service Manual
No.
Description
Part Code
Qty
ASH-09AIE2 ASH-12AIE2
Product Code CB146N38400_L31222 CB146N38500_L31222
1 Front Panel 27230001300 27230001300 1
2 Filter Sub-Assy 1112208201 1112208201 2
3 Screw Cover 24252019 24252019 1
4 Membrane 63062017 63062017 1
5 Front Case Assy 2001237501 2001237501 1
6 Guide Louver 10512119 10512119 1
7 Helicoid Tongue 26112486 26112486 1
8 Air Louver 10512160 10512160 2
9 Shaft of Guide Louver 1054202001 1054202001 2
10 Drainage Pipe Sub-assy 0523204101 0523204101 1
11 Rear Case assy 2220229501 2220229501 1
12 Electric Box Assy 10000201391 10000201392 1
13 Electric Box Cover 20122106 20122106 1
14 Shield Cover 01592076 01592076 1
15 Crank 73012005 73012005 1
16 Step Motor 1521210701 1521210701 1
17 Indicator Light Cover 22242084 22242084 1
18 Indicator Shield Cover 22242083 22242083 1
19 Display Board 30568112 30568112 1
20 Electric Box 20112086 20112086 1
21 Capacitor CBB61 3301000213 3301000213 1
22 Main Board 30138000407 30138000407 1
23 Terminal Board 42011233 42011233 1
24 Shield Cover 01592076 01592076 1
25 Wall Mounting Frame 0125201801A 0125201801A 1
26 Fan Motor 15012141 15012141 1
27 Motor Press Plate 26112191 26112191 1
28 Cross Flow Fan 10352423 10352423 1
29 Evaporator Assy 01002957 01002958 1
30 Cold Plasma Generator 11140016 11140016 1
31 Evaporator Support 24212108 24212108 1
32 Fan Bearing 76512210 76512210 1
33 Damping Washer Sub-assy 76512011 76512011 1
34 Axile Bush Sub-assy 10542024 10542024 1
35 Pipe Plug (Outlet) 76712020 76712020 1
36 Remote Controller 30510125_L31222 30510125_L31222 1
37 Temperature Sensor 390000453 390000453 1
38 Temperature Sensor 39000305 39000305 1
39 Connecting Cable 400204056 400204056 1
40 Power Cord / / /
Above data is subject to change without notice.
