Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model ASH-09AIE2 ASH-12AIE2
Product Code CB146038401_L31222 CB146038501_L31222
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) W 2600(450~3230) 3500(450~3230)
Heating Capacity(Min~Max) W 2800(450~4100) 3800(450~4100)
Cooling Power Input(Min~Max) W 870(200~1420) 1150(200~1420)
Heating Power Input(Min~Max) W 900(200~1550) 1100(200~1550)
Cooling Current Input A 3.8 5.1
Heating Current Input A 4.0 4.9
Rated Input W 1550 1650
Rated Cooling Current A 6.3 6.9
Rated Heating Current A 6.9 7.3
Air Flow Volume (SH/H/M/L) m
3
/h 600/520/370/280 680/560/410/300
Dehumidifying Volume L/h
0.8 1.4
EER W/W 2.99 3.04
COP W/W 3.11 3.45
SEER
5.6
5.6
SCOP / /
Application Area m
2
12-18 16-24
Indoor
Unit
Indoor Unit Model ASH-09AIE2 ASH-12AIE2
Indoor Unit Product Code CB146N38400_L31222 CB146N38500_L31222
Indoor Unit Fan Type Cross-ow Cross-ow
Indoor Unit Fan Diameter Length(DXL) mm Ф92X596 Ф92X596
Cooling Speed (SH/H/M/L) r/min 1350/1100/900/700 1350/1150/950/750
Heating Speed (SH/H/M/L) r/min 1350/1140/980/820 1350/1190/1020/850
Indoor Unit Fan Motor Power Output W 10 10
Indoor Unit Fan Motor RLA A 0.18 0.18
Indoor Unit Fan Motor Capacitor μF 1.2 1.2
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7 Ф7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 610X24X294 610X24X294
Swing Motor Model MP24BA MP24BA
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Indoor Unit Sound Pressure Level (SH/H/M/L) dB (A) 41/38/30/24 42/39/31/25
Indoor Unit Sound Power Level (SH/H/M/L) dB (A) 55/52/44/38 56/53/45/39
Indoor Unit Dimension (WXHXD) mm 770X283X201 770X283X201
Indoor Unit Dimension of Carton Box (LXWXH) mm 844X342X261 844X342X261
Indoor Unit Dimension of Package (LXWXH) mm 847X345X276 847X345X276
Indoor Unit Net Weight kg 8 9
Indoor Unit Gross Weight kg 9.5 10.5
