1 Left Side Plate 01303200P 1 AL
2 Brushless DC Motor 1501308511 1 AX
3 Motor Support 01703136 1 AL
4 Condenser Assy 011002060182 1 BE
5 Top Cover Sub-Assy 000051060003 1 AP
6 Rear Grill 01475014 1 AG
7 Clapboard Sub-Assy 01233180 1 AK
8 Compressor and Fittings 009001060066 1 BH
9 Compressor Gasket 009012000027 3 -
10 4-way Valve Assy 030152060069 1 AV
11 Big Handle 2623343106 1 AE
12 Cut off Valve 07130239 1 AH
13 Cut off Valve 071302391 1 AM
14 Valve Support 0171314201P 1 AE
15 Front Grill 22413044 1 AL
16 Front Panel Assy 0153305205 1 AU
17 Axial Flow Fan 10333011 1 AN
18 Base Plate Sub-Assy 017000060080P 1 AR
19 Electric Box Assy 100002061044 1 BH
20 Electric Box Sub-Assy 017007060170 1 BF
21 Filter Board none 0 -
22 Main Board 300027060161 1 BE
23 Reactor 43130184 1 AS
24 Wire Clamp 71010103 2 AB
25 Terminal Board 422000060016 1 AH
MODEL: ASH-13BIF2 Wall mounted unit: OUTDOOR
The data are subject to change without notice.
