Service Manual
24K
1
234
5
6
7
8
9
● Top view
● Bottom view
1 Terminal of compressor
2
Terminal of electronic
expansion valve
3
Terminal of temperature
sensor
4
Overload terminal of
compressor
5 Terminal of outdoor fan
6 Live wire
7 Communication wire
8 Earthing wire
9 Neutral wire
