112
Service Manual
Procedure Steps
1.Remove big handle
2. Remove top cover
top cover
big handle
valve cover
Before disassamble．
Remove the screws fixing big handle、valve
cover and then remove them.
Remove the screws fixing top panel and
then remove the top panel.
12K
