Service Manual
Outdoor
Unit
Model of Outdoor Unit ASH-09AIR ASH-12AIR
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI GREE DAIKIN DEVICE
CO., LTD
Compressor Model QXA-A091zE190A 1GDY23AXD
Compressor Oil 68EP FVC50K
Compressor Type Rotary Rotary
L.R.A. A 16.5 16.5
Compressor RLA A 4.5 4
Compressor Power Input W 942 845
Overload Protector 1NT11L-6233 1GDY23AXD-05
Throttling Method Capillary Capillary
Operation temp
o
C 16~30 16~30
Ambient temp (cooling)
o
C -15~48 -15~48
Ambient temp (heating)
o
C -15~24 -15~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7.94
Rows-n Gap mm 1-1.4 1-1.4
Coil Length (LXDXW) mm 692X19.05X506 731X19.05X550
Fan Motor Speed rpm 900/600 900/600
Output of Fan Motor W 30 30
Fan Motor RLA A 0.4 0.4
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 1600 2200
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ400 Φ438
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 50/-/- 51/-/-
Sound Power Level (H/M/L) dB (A) 60/-/- 63/-/-
Dimension (WXHXD) mm 776X540X320 842X596X320
Dimension of Carton Box (LXWXH) mm 820X355X580 878X360X630
Dimension of Package (LXWXH) mm 823X358X595 881X363X645
Net Weight kg 27 31
Gross Weight kg 29.5 34
Refrigerant R410A R410A
Refrigerant Charge kg 0.7 0.85
Connection
Pipe
Length m 5 5
Gas Additional Charge g/m 20 20
Outer Diameter Liquid Pipe mm Φ6 Φ6
Outer Diameter Gas Pipe mm Φ9.52 Φ12
Max Distance Height m 10 10
Max Distance Length m 15 20
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
