Service Manual
2. Specications
2.1 Specication Sheet
Model ASH-09AIR ASH-12AIR
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) W 2500(600~2800) 3200(600~3500)
Heating Capacity(Min~Max) W 2750(600~3000) 3400(600~3800)
Cooling Power Input(Min~Max) W 800(120~1300) 1020(120~1400)
Heating Power Input(Min~Max) W 780(120~1400) 995(120~1500)
Cooling Current Input A 3.6 4.5
Heating Current Input A 3.5 4.4
Rated Input W 1400 1500
Rated Current A 6.7 7.2
Air Flow Volume(SH/H/M/L/SL) m
3
/h 500/400/300/250/- 500/400/300/250/-
Dehumidifying Volume L/h 0.8 1.4
EER W/W 3.13 3.14
COP W/W 3.53 3.42
SEER 5.8 6.1
HSPF / /
Application Area m
2
12-18 15-22
Indoor
Unit
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ85X596 Φ85X596
Cooling Speed(SH/H/M/L/SL) r/min 1320/1100/920/730/- 1320/1100/920/730/-
Heating Speed(SH/H/M/L/SL) r/min 1350/1200/1100/1000/- 1350/1200/1100/1000/-
Fan Motor Power Output W 10 10
Fan Motor RLA A 0.15 0.15
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length(LXDXW) mm 592X25.4X266.7 592X25.4X266.7
Swing Motor Model MP24AA MP24AA
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level(SH/H/M/L/SL) dB (A) 38/34/31/28/- 39/34/31/28/-
Sound Power Level(SH/H/M/L/SL) dB (A) 50/46/43/40/- 53/47/43/40/-
Dimension(WXHXD) mm 790X265X174 790X265X174
Dimension of Carton Box(LXWXH) mm 870X248X355 870X248X355
Dimension of Package(LXWXH) mm 873X251X370 873X251X370
Net Weight kg 9 9
Gross Weight kg 10.5 10.5
8
