9. SUMMARY OF THE MODULE SETTINGS
Main menu Submenu/Option Range Default
Goal C
Setting the desired temperature in the cooling mode. -10 to +55 +10,0°C
Goal H
Setting the desired temperature in the heating mode.
-10 to +55
+25,0°C
Function Operated
Slave unit mode. The module is controlled by an external voltage 0-
10V.
Operated
Reg. P
Autonomous pressure (evaporation temperature) control mode
Reg. T*
Autonomous temperature control mode for cooling
Reg. T+
Autonomous temperature control mode for heating
Reg. Tx
Autonomous temperature control mode for switched
cooling/heating
Defrost Mode Off
Defrosting the indoor unit evaporator is not in use Off
External
Defrosting with an external support (heating cable
etc.)
Reverse
Defrosting by switching from cooling to heating
mode.
Period
Setting the minimum time period between defrosting
cycles
0.1 to 99.9 1 hour
Length
Setting the maximum duration of defrosting 1.0 to 99.9 10 min
Start
Setting the temperature to start defrosting -20 to +5,0 -5,0°C
Stop
Setting the temperature to stop defrosting +3 to +25.0 +7,0°C
Outputs Relay 1 Function ON/OFF
The relay is controlled by On/Off
input.
On/Off
Compres.
The relay is controlled according to
the compressor
Defrost
The relay is controlled according to
the operation (Heat/Cool)
Error
The relay is controlled according to
the error state
Heat/Coo
The relay is controlled according to
the operation (Heat/Cool)
Limiting
Min sp.
The relay to limit
the long lasting
compressor load.
Max sp.
Delay
Logic Direct
Relay switches with direct logic Direct
Inverse
Relay switches with inverse logic
Relay 2 Function
This setting is the same as setting the Relay 1 Compres.
Logic
This setting is the same as setting the Relay 1 Direct
Relay 3 Function
This setting is the same as setting the Relay 1 Error
Logic
This setting is the same as setting the Relay 1 Direct
DC Vent Fixed
Setting the speed and mode (Co, Fa, On) of the
indoor fan
Off
Auto 1
Fan speed according to the compressor speed 1:1
Auto 2
Fan speed of 60-200% of the compressor speed
Off
Output not used
Reg.cons Time con
Setting the time constant of the module. 10 to 999 30 sec.
Prop.con
Setting the proportional constant of the module. 0 to 999 35
Int.cons
Setting the integral constant of the module. 0 to 999 0
Der.cons
Setting the derivative constant of the module. 0 to 999 60
Display Backlit
Setting the LCD backlight. 1 to 16 8
Contrast
Setting the LCD contrast. 1 to 16 8
IdleTime
Setting the time period of the operator inactivity 10 to 999 60
Language
Setting the language version CZ / EN EN
Password
Enter the password before setting the module. After logging in, you can perform
settings for about 30 minutes. Without knowing the password, you can only adjust
the contrast and backlight brightness of the display.
