SDV5-140DHA / SDV5-160DHA
Figure 2.2: SDV5-140,160DHA dimensions (unit: mm)
(W)
Size of Return Air Inlet
(W)
(L)
Size of Air Outlet
(L)
Refrigerant piping (gas side)
Refrigerant piping (liquid side)
Connect to water piping
Position of lifting bolt
Return Air Inlet Flange
Return Air Inlet Flange
Connection hole
Electric control box assembly
Return Air Inlet
Air Outlet
