Sinclair SDV5 Series Service Manual

201806 9
SDV5-200DHA / SDV5-250DHA / SDV5-280DHA
Figure 2.3:SDV5-200,250,280DHA dimensions (unit: mm)
Size of ReturnAir Inlet
Position of lifting bolt
Size of Air Outlet
Refrigerant piping (gas side)
Refrigerant piping (liquid side)
Connect to water piping
Return Air Inlet
Air Outlet
Positions of 4-12*25 lifting bolts
Electric control box assembly
Connection hole (for the air duct)
