Sinee A90-4T5R6B User Manual

User Manual of A90 Series Inverter
247
terminal status 1
to X5. The five-bit digit tubes from left to right are:
X5
X4
X3
X2
X1
0/1
0/1
0/1
0/1
0/1
The actual display effect is: 00000.
★
: “0” means that the current terminal function is
invalid; and “1” means that the current terminal function
is valid.
F18.23
Digital input
terminal status 2
Display the current valid status of the input terminals AI1
and AI2. The five-bit digit tubes from left to right are:
*
AI2
AI1
*
*
0/1
0/1
0/1
0/1
0/1
The actual display effect is: 0000.
★
: The analog input terminals AI1 and AI2 of the A90
series inverter can be used for digital input only.
“0” means that the current terminal function is invalid;
and “1” means that the current terminal function is valid.
F18.24
Digital input
terminal status 3
*
*
*
*
*
0/1
0/1
0/1
0/1
0/1
The actual display effect is: 00000.
“0” means that the current terminal function is invalid;
and “1” means that the current terminal function is valid.
F18.25
Output terminal
state
Display the current valid status of the output terminals
R1/Y1. The five-bit digital tubes from left to right are:
*
*
R1
*
Y1
0/1
0/1
0/1
0/1
0/1
The actual display effect is: 000.
“0” means that the current function terminal is invalid;
and “1” means that the current function terminal is valid.
F18.26
AI1
Display the per-unit value of the current analog input
channel 1 (AI1) relative to 100.0%. Scope: 0.0 - 100.0.
%
F18.27
AI2
Display the per-unit value of the current analog input
channel 2 (AI2) relative to 100.0%. Scope: 0.0 - 100.0.
%
F18.33
Count value
F18.34
Actual length
m
F18.35
Remaining time
of regular running
Display the remaining time of regular running. For
specific function. see the description of the F16.05
regular running function. Scope: 0.0 - F16.05.
min
F18.39
VF separation
target voltage
Display the VF separation target voltage in a real-time
manner. Scope: 0.0 to rated voltage of the motor
V
F18.40
VF separation
output voltage
Display the actual output voltage of VF separation in a
real-time manner. Scope: 0.0 to rated voltage of the
motor
V
