User Manual of A90 Series Inverter
299
8
CRC check Hi
4
C
Register value Hi
(F19.02)
00
9
Register value Lo
(F19.02)
00
10
Register value Hi
(F19.03)
01
11
Register value Lo
(F19.03)
2C
12
Register value Hi
(F19.04)
00
13
Register value Lo
(F19.04)
00
14
Register value Hi
(F19.05)
00
15
Register value Lo
(F19.05)
00
16
CRC check Lo
53
17
CRC check Hi
5B
*
Tail
≥3.5 characters (idle)
2) Check whether the line is connected.
Send: 01 08 00 00 AA 55 5E 94
Return: 01 08 00 00 AA 55 5E 94 (normal)
Return: 01 88 04 47 C3 (exception, assuming a slave fault)
Send the invoice to
Normal Return
Exception Return
*
Frame header
≥3.5 characters (idle)
1
Address
01
Address
01
Address
01
2
Function
08
Function
08
Function code
88
3
Sub-function
code Hi
00
Sub-function code
Hi
00
Exception code
04 (assumption)
4
Sub-function
code Lo
00
Sub-function code
Lo
00
CRC check Lo
47
5
Data Hi
AA
Data Hi
AA
CRC check Hi
C3
6
Data Lo
55
Data Lo
55
7
CRC check Lo
5E
CRC check Lo
5E
8
CRC check Hi
94
CRC check Hi
94
*
Tail
≥3.5 characters (idle)
3) Change the carrier frequency (F00.23) to 4.0kHz.
(use the function code 0x06 as such
function codes are expected to be stored in EEPROM after change)
Send: 01 06 00 17 00 28 39 D0
