User Manual of A90 Series Inverter
58
5.5.1
Terminal control of start and stop
Function
code
Function code
name
Parameter description
Default
setting
Attribute
F00.03
Options of
terminal control
mode
0: terminal RUN (running) and F/R
(forward/reverse)
1: terminal RUN (forward) and F/R
(reverse)
2: terminal RUN (forward), Xi (stop)
and F/R (reverse)
3: terminal RUN (running), Xi (stop)
and F/R (forward/reverse)
0
Terminal RUN:
Xi terminal is set to “1: terminal RUN”
Terminal F/R:
Xi terminal is set to “1: running direction F/R”
Terminal control can be divided into two types: two-line control and three-line
control.
Two-line control:
F00.03=0: the terminal RUN is enabled and the terminal F/R controls
forward/reverse running.
Enable/Disable the terminal RUN to control the start and stop of the inverter, and the
terminal F/R to control the forward/reverse running. If F00.21 is set to 1 and reverse
running is disabled, the F/R terminal will not be available. When the mode of deceleration
to stop is selected, the logic diagram is as shown in Fig. 5-2 (b).
F00.03=1: the terminal RUN controls forward running, and the terminal F/R is in
the reverse mode.
Enable/Disable the terminal RUN to control the forward running and stop of the inverter,
and the terminal F/R to control the reverse running and stop. When the terminals RUN and
F/R are enabled simultaneously, the inverter will be stopped. If reverse running is disabled,
the terminal F/R will not be available. When the mode of deceleration to stop is selected,
the logic of forward/reverse running is as shown in Fig. 5-2 (d).
