24
Zigzag Sewing Machine | Instruction Manual and Parts List
3.24
Thread Anti-
Spill Net
Usage
Figure 33
145 mm
When using synthetic threads that
easily spill off the cone ‘1’, slip the
thread anti-spill net ‘2’ furnished
with the machine over the thread
from the bottom of cone ‘1’ leaving
the thread end to hang free at the
top of thread anti-spill net ‘2’.
(Figure 33)
1
2
2
1
3.25
Knee Lifter
Installation
Figure 34
Knee lifter mounting (Figure 34)
The knee lifter bracket ‘1’ position is
145 mm from the edge at the under-
neath table cutout.
Then fasten the knee lifter bracket
under the table ‘2’.
To Next Page
