Singer 20U109 - Fittings for Zipper and Cord Sewing

28
Zigzag Sewing Machine | Instruction Manual and Parts List
3.28
The zipper presser foot ‘1’ is
designed to facilitate the placement
of stitching closed to a raised edge
as the following condition. (Figure
40)
1. Needle position selector: Center
position
2. Stitch width regulate: Straight
stitch position
3. Needle plate: Straight stitch ‘3’
Zigzag stitch ‘2’
4. Feed dog: Straight stitch ‘5’
Zigzag stitch ‘4’
Fittings for
Zipper and
Cord Sewing
Figure 40
606695
606588(20U-109/109C/309)
606502(20U-112/112C)
606697
605652(20U-102/102C/309)
606402(20U-112/112C)
606691
1
2
3
4
5
Zipper insertion Corded seams
Caution
Switch off the
machine.
