Singer 20U109 - Page 48

45
Zigzag Sewing Machine | Instruction Manual and Parts List
6.7
Hook and
Bobbin Case
Components
109 109C 112 112C 309 910
1 606517 Hook shaft collar assembly 2 2 2 2 2 2
2 606518 Hook shaft collar screw 4 4 4 4 4 4
3 606516 Set screw 1 1 1 1 1 1
4 606519 Hook shaft bushing (short) 1 1 1 1 1 1
5 541689 Bevel gear assembly 1 1 1 1 1 1
6 504101 Bevel gear screw 2 2 2 2 2 2
7 606516 Set screw 1 1 1 1 1 1
8 606515 Hook shaft bushing (long) 1 1 1 1 1 1
9 606520 Hook shaft 1 1 1 1 1 1
10 606410 Gear shield 1 1 1 1 1 1
11 606444 Screw 1 1 1 1 1 1
12 606513 Bobbin 1 1 1 1 1 1
13 606683 Rotating hook assembly 1 0 0 0 1 1
606683C Rotating hook assembly 0 1 0 0 0 0
606514 Rotating hook assembly 0 0 1 0 0 0
606514C Rotating hook assembly 0 0 0 1 0 0
14 606684 Rotating hook set screw 2 2 2 2 2 2
15 606512 Bobbin case assembly 1 1 1 1 1 1
16 606510 Hook position finger 1 1 1 1 1 1
17 606511 Position finger screw 1 1 1 1 1 1
No. Part No. Description
Qty
