Singer 20U109 - Page 50

47
Zigzag Sewing Machine | Instruction Manual and Parts List
6.8
Feed Regulat-
ing Dial and
Feed Reverse
Lever
Components
109 109C 112 112C 309 910
1606618 Spring 111110
2 606617 Stud lock pin 1 1 1 1 1 0
3 606609 Feed regulating stud 1 1 1 1 1 0
4 554138-383 Feed regulation dial 1 1 1 1 1 0
5 543803-004 Dial screw washer 1 1 1 1 1 0
6 544218-053 Dial screw 1 1 1 1 1 0
7 606610 Hinge stud 1 1 1 1 1 0
8 606685 Feed regulator & fork assembly 1 1 1 1 1 0
9 606611 Feed regulator assembly 1 1 1 1 1 0
10 606686 Screw 1 1 1 1 1 0
11606494 Hingescrewnut 111110
12 606496 Hinge screw 2 2 2 2 2 0
13 606495 Feed connecting link 2 2 2 2 2 0
14 606509 Feed fork connection. 1 1 1 1 1 0
15 606496 Hinge screw 1 1 1 1 1 0
16606494 Hingescrewnut 111110
17 606615 Reverse lever link assembly 1 1 1 1 1 0
18 606434 Clamp screw 1 1 1 1 1 0
19606612 Spring 111110
20606614 Springbracket 111110
21 606602 Screw 1 1 1 1 1 0
22 554131-467 Reverse lever assembly 1 1 1 1 0 0
551131-467 Reverse lever assembly 0 0 0 0 1 0
23 374564 Adjusting screw 1 1 1 1 0 0
24 554134 Adjusting screw friction 1 1 1 1 0 0
25 554136 Indicator plate 1 1 1 1 0 0
26 504010-453 Indicator plate screw 2 2 2 2 0 0
27 554135 Adjusting screw stopper 1 1 1 1 0 0
28 544213-001 Stopper set screw 1 1 1 1 0 0
29 53C/7-1 Stitch length crank 0 0 0 0 0 1
30 53C/7-2 Stitch length crank connecting rod 0 0 0 0 0 1
31 53C/7-3 Connecting screw pin 0 0 0 0 0 1
32 GB/T896-1986 E ring 0 0 0 0 0 1
33 GB/T6713-2000 Nut 0 0 0 0 0 4
34 53C/7-4 Stitch length link 0 0 0 0 0 1
No. Part No. Description
Qty
