Service Manual
Motor Belt Tension
99
Rev. n .
o
Too tight a motor belt tension can cause the machine to run slow and will overload the
motor. Too loose a motor belt tension will create belt noise and may cause jumping of the
belt teeth on cogged motor pulley.
1- Remove arm top cover and right side cover.
2- Loosen adjusting screws (A).
3- Bring the motor up or down until the machine is running at its adequate highest speed.
4- Tighten screws (A).
Adjustment:
358487-001 Mar./2005
