In order to meet the customer minimum lubrication requirement, the machine must be
lubricated as indicated on pages 104/105/106/107.
Only Singer oil and Singer grease must be used.
Use of parafin based oil, or non-silicon type grease, will create a build up of residue on the
bearing surfaces. The self-lubricating qualities of the bearings will be defeated by clogging
of the pores in the bearing if such oil or grease are used.
All thread, lint, or any foreign matter must be removed before lubrication.
O = Singer oil
G = White grease for lubrication.
Applied to cam surfaces, cover entire surface.
To gears, cover each tooth.
To slides, cover entire surface.
Do not apply grease to oil-impregnated metal parts.
Applying lubrication
l
l
l
Lubrication
Service Manual
108
Rev. n .
o
358487-001 Mar./2005
