Singer 2802 - Page 11

Removal:
Replacement:
1. Place bobbin winder in the “OFF” position.
2. Remove two arm top cover screws (A) and (B).
3. Remove the arm top cover by pulling it straight upwards.
1. Replacement is the same as removal in reverse order.
Arm Top Cover
Service Manual
10
Rev. n . o
358487-001 Mar./2005
