Service Manual
Stitch length regulator spring tension
For 2818/2868
97
Rev. n . o
The reverse button must operate smoothly with the stitch length set at maximum stitch.
1. Remove arm top cover, right side cover, motor belt and hand wheel.
2. Loosen screw (A) in feed regulator assembly.
3. Upon loosening this screw, the stud (C) will rotate, allowing the spring (B) to loosen
tension.
4. Rotate stud (C) one complete counterclockwise revolution only to place proper tension
on spring (B).
5. Tighten screw (A).
Adjustment;
.
358487-001 Mar./2005
