- Place thread and spool holder onto spool pin (1). For
smaller spools of thread place spool holder with small
side next to spool. (2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension
discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin to right. (6)
- Hold thread end (7). Step on foot control pedal. (8)
- Cut thread (9). Press bobbin to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel
will not turn. To start sewing, push the bobbin winder
spindle to the left (sewing position).
Please Note:
18
Winding the bobbin
GB
1
2
3
4
5
6
7 8 9
10
