Page #89 background imageLoading...
Page #89 background image
4
5
6
7
3
1
Attention:
Disconnect the machine from the electrical supply by
removing the plug from the main socket. When cleaning
the machine, it must always be disconnected from the
electrical supply.
Turn the handwheel until the needle is fully raised. Open the
hinged front cover and unscrew the needle plate screws with
the screw driver (1).
Use the brush supplied to clean the whole area (2).
Remove the bobbin case. Snap the two hook retaining arms
(3) outwards. Remove the hook race cover (4) and the hook
(5) and clean with a soft cloth. Lubricate at the point (6) (1-2
drops) with sewing machine oil. Turn the handwheel until the
hook race (7) is in the left position. Replace the hook (5).
Replace the hook race cover and snap back the two hook
retaining arms. Insert the bobbin case and bobbin and
replace the needle plate.
Fabric lint and threads must be removed regularly. Your
machine should be serviced at regular intervals at one of
our service centers.
Remove the needle plate:
Cleaning the feed dogs:
Cleaning and lubricating the hook:
Important:
Maintenance
2
GB
82

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Singer 3116 Simple and is the answer not in the manual?

Singer 3116 Simple Specifications

General IconGeneral
Presser FootSnap-On
Free ArmYes
TypeMechanical
Adjustable Stitch LengthYes
Adjustable Stitch WidthNo
Reverse StitchYes
Buttonhole Styles1
Stitch ApplicationsBasic, Decorative, Stretch
Stitch OptionsBasic, Decorative, Stretch
Presser FeetAll-Purpose Foot, Buttonhole Foot, Zipper Foot
Included AccessoriesNeedles, bobbins, screwdriver, seam ripper, spool cap
Buttonhole Style1-step
