INTRODUCTION
Optimal use and maintenance are described in these instructions. This product is not intended for industrial or commercial use.
Additional assistance, by region, may be found online at www.singer.com.
1. Accessory Tray / Free Arm — Provides a at surface
when sewing and allows storage for your accessories.
Remove the accessory tray to use the free arm which makes
it easier to sew, e.g., trouser hems and sleeves.
2. Thread Knife — For trimming thread ends at the end of
sewing.
3. Threading Slots — Thread paths with tension discs and
take up lever.
4. Thread Tension Dial — Adjustable for setting the desired
tension for your stitch, thread and fabric.
5. Reverse Button — Press and hold to sew in reverse or to
make a tie-o, e.g., when securing the beginning or ending
of a seam.
6. Display — Current stitch and settings are displayed.
7. Hand Wheel — Used to manually control the movement of
the needle and the thread take-up lever.
8. Function Buttons — Functions used to make
your sewing more convenient. Control the stitch width and
the stitch length.
9. Bobbin Cover — protects the bobbin while sewing.
10. Bobbin Cover Release Button — push to open the bobbin
cover.
Intended Use
Machine Overview
7
9
8
6
5
1
2
3
4
10
