Singer CONFIDENCE 7463 - Sec. 5 Needle Threader Height; Checking Needle Threader Height; Adjusting Needle Threader Height

- 15 -
Sec.5 Needle threader height
Checking:
1. Select straight stitch at center needle position.
2. Raise needle to its highest position by rotating hand wheel towards you.
3. Lowering needle threader lever (A), check and see if hook is inserted into the needle hole.
Adjustment:
1. Remove face cover
2. Turning hand wheel by hand, bring needle bar to its highest position.
3. Loosen of threader stopper screw(B)
4. Insert hook into the upper side of needle-hole moving the needle bar (C).
5. While holding above situation, tighten the screw attaching the threader stopper onto stopper
pin (D).
6. The direction of threader stopper should be facing toward you as the threader stopper (E) may
hit the support.
Added : November, 2006
A
C
D
B
E
