Singer CONFIDENCE 7463 - Sec. 17 Timing Belt Tension; Adjusting Timing Belt Tension

- 43 -
Sec. 17 Timing Belt tension
Adjustment
1. Remove face cover.
2. Loosen the screw (A) on idler pulley bracket.
3. Tighten the screw (A) after checking the belt tension.
Note: Be sure to recheck “Needle Timing to shuttle” after adjustment.
Added : November, 2006
A
