- 48 -
CPU Board – 3 (other models) Addition
Component number for half-step version is 87555 and for full-step version is 87585.
Be sure to check number printed on board.
87585
Added: January 2006
Motor for needle zigzag
Motor for material feeding
5P connector cable
Connect with AC board
Cam sensor harness
Bobbin winding switch
Buttonhole stitch SW
Reverse stitch SW
Serial port
Only for factory
Foot control
Jumper cord
4P Connector cable
Connect with switch board
Only for Japan market
13P Connect cable
Connect with switch board
4P Connector cable
Connect with CPU
Not use
