-9 -
Disassembling of covers for model 7422
An additional bottom cover is provided on model 7422.
Remove screws S for front cover and then 5 screws on the bottom cover.
Disassembling of covers for model 7424・7426・7428 *7436
An additional bottom cover is provided on model 7424, 7426 ,*7436 and 7428.
Remove screws S for front cover and then 6 screws on the bottom cover.
Bottom cover
S
Bottom cover
S
