Singer SDHM -10M - Continuous Drainage Setup

11
ENGLISH
Continuous drainage
1. Open the cover on the back of the dehumidifi er.
2. Take out the water tank
3. Insert a PVC pipe with 9.5mminner diameter 9.5mm, and the rec-
ommended length is 200mm; put the other side into a container,
such as a bucket.
Step:
1. Take out the water tank.
3. Insert the pipe into the hole of
water outlet port
2. Remove the plastic at the water
level place
4. Put the drain-pipe to the spe-
cifi c location
