4
5
1 2
3
6
2
Water temperature selector
1
4
Water level button
Press this button to select water level.
5
Press this button to select water
temperature.
Process button
Press this button to select the process
you need.
Start/hold button
Press this button to start/pause the
washing machine.
Power button
Press this button to turn on/off the
washing machine. Do not turn on the
washing machine again until 3 minutes
later after it is turned off. The washing
machine will turn off automatically
when the program is finished, and it
will turn off automatically if you do not
press the start button to start the
machine within 10 minutes after press
the power button to turn on the
machine.
3
SPECIFICATIONS
Rated voltage Rated frequency
Rated input power
Rated water volume
(high water level )
230~240V
50Hz
480W
70L
Net weight
7.0kg
569mmX583mmX957mm
38kg
Rated wash and spin
capacity
Dimension
Water pressure
0.05MPa-0.5MPa
957mm
5
83
m
m
5
6
9
m
m
-3-
CONTROL PANEL
