© Nov. 2022 1-2 GTZZ15J Operation Manual
PERFORMANCE PARAMETERS
Table 1-1 GTZZ15J specifications (continued)
Items
AB15J (Metric) AB480J (Imperial)
Turning radius (outside)
4.5 m 14ft 9in
Max allowable side force 400 N 90 lbf
Max operating noise level
82 dB
IP rating
IP54
POWER PARAMETERS
Engine (rated power/rpm)
Options
35.3 kW/3000 rpm/4TNV88-ZCDCSI/Yanmar/China T4
34.5 kW /3000 rpm/ TNV88-BDFLTC/Yanmar/China T3
35.5 kW/3000rpm/4TNV88C-DFLT/Yanmar/EU Stage V, EPA Tier 4F
36.3 kW/2800 rpm/D2011L3I/Deutz/EU Stage 3A, EPA Tier 3
Hydraulic tank capacity
90 L
19.8gal (UK)/23.8gal (US)
Oil capacity of hydraulic tank
75 L
16.5 gal (UK)/19.8 gal (US)
Fuel tank capacity
70 L
15.4gal (UK)/18.5gal (US)
Hydraulic system pressure
28 MPa
3046 psi
Battery (voltage, capacity) 12V/220Ah
System voltage 12 VDC
Control voltage
12 VDC
GROUND BEARING DATA
Max tire load
3700 kg
8157 lb
Pressure against ground
570 kPa
83 psi
ENVIRONMENT REQUIREMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium battery)
-20℃～40℃ -4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gases, inflammables and explosives.
WEIGHT
