GTZZ15J Operation Manual 1-1 © Nov. 2022
1 PERFORMANCE PARAMETERS
Table 1-1 GTZZ15J specifications
Items
AB15J (Metric) AB480J (Imperial)
DIMENSION PARAMETERS
Max platform height
14.7m
48ft 3in
Max working height
16.7 m 54ft 9in
Max horizontal reach 8.5 m 27ft 11in
Max horizontal working envelope
9.1 m 29ft 10in
Overall length (stowed)
7.35 m 24ft 1in
Overall length (transport)
7.35 m 24ft 1in
Overall width (stowed)
2.26 m 7ft 5in
Overall width (transport)
2.26 m 7ft 5in
Overall height (stowed)
2.22 m 7ft 3in
Overall height (transport)
2.22 m 7ft 3in
Wheelbase 2.03m 6ft 8in
Ground clearance 0.32 m 1ft 1in
Tire size (spec/type)
Options
33×12-20 (solid)
315/55D20 (foam-filled)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
PERFORMANCE PARAMETERS
Max platform capacity 250kg (unrestricted/2 persons) 551 lb (unrestricted/2 persons)
Turntable rotation/continuity
355 °/noncontinuous
Platform rotation 160°
Max drive speed (stowed) (2WD)
7 km/h
4.4 mph
Max drive speed (stowed) (4WD)
5 km/h
3.1 mph
Max drive speed (raised)
1.1 km/h
0.67 mph
Drive mode (drive×steer) 4WD (2WD)×2WS
Gradeability 30 % (2WD)/40% (4WD)
Turntable tail-swing
0 m
0 ft
Max allowable inclination 5°
Turning radius (inside)
1.8 m
5ft 11in
