© Nov. 2022 7-2 GTZZ15J Operation Manual
OPERATING THE MACHINE
Figure 7-1 Position of least forward stability
1. Articulated boom fully raised;
2. Main boom kept horizontal;
3. Telescopic boom fully extended;
4. Jib boom kept horizontal;
5. The machine will tip over in the direction as indicated by the arrow if overloaded or operated on surfaces
beyond the maximum allowable inclination angle.
